Hynetek made a spectacular appearance at the 14th Asia Power Supply Technology Development Forum and was honored with the Domestic Analog IC Industry Product Innovation Award.

1 4, 2024

On December 23, 2023, the 14th Asia Power Supply Technology Development Forum, organized by the well-known power industry information technology exchange platform Century Power Net, was grandly held in Shenzhen with four major venues hosting over 3,000 enthusiastic engineers. The Hynetek team showcased a series of digital energy and intelligent fast-charging products, engaging with industry leaders to jointly explore future technological innovations for development.Concurrently, at the 2023 Annual Power Industry Supporting Brands Award Ceremony held on the same day, Hynetek Corporation was honored with the "Domestic Analog IC Industry Product Innovation Award".

企业荣誉介绍PPT内容页 (1).jpg

In recent years, Hynetek has completed an integrated product portfolio surrounding the USB Type-C ecosystem and has been committed to enhancing energy utilization efficiency and researching energy control technologies. Leveraging its R&D strengths, the company focuses on developing digital power control chips, high-voltage driver chips, power conversion chips, and modules targeting industrial applications such as ICT (Information and Communication Technology) servers, data centers, photovoltaic inverters, and energy storage systems. Winning this award signifies the industry experts' recognition and endorsement of Hynetek's semiconductor analog chip products.

At the forum, Mr. Xie , Chairman of Hynetek Semiconductor, served as a distinguished guest speaker and shared insights into 'Introduction to HP1010 - A High-Performance Totem-Pole Bridgeless PFC Digital Controller'. He engaged attendees in discussions about the development and technology of totem-pole PFC digital controllers. The session was packed, receiving an enthusiastic response, while the B16 booth featuring Hynetek outside the venue was also bustling with visitors.

图片                图片

The main star products we showed in this exhibition are:

HP1010:Industry's First Digital Totem Pole PFC Controller

The HP1010 is a digital multi-mode PFC controller of Totem-pole topology(TPPFC). Embracing the simplicity and higher efficiency,  HP1010 engineered robustness and intelligent control using Hynetek  patented technologies. HP1010 gives special care to the vulnerability of the switching power FETs, directly exposed to all kinds of harsh conditions in such a bridgeless topology. HP1010 is the ultimate choice of a global platform design. It supports both high/low AC lines and HVDC operations. The high performance of HP1010 comes in a small 4 mm x4 mm QFN-24 package with I2C and UART communication interface. Design with HP1010 has never been simpler before. Through an intuitive Graphic User Interface(GUI) developed by Hynetek, any designer can have not only a quick start but a sophisticated modern design with customised register settings.


(600 W evaluation board utilizing the HP1010 controller)

Chip Features:

• High flexibility digital PWM with a selectable operating frequency range from 20 kHz to 200 kHz

• High-performance 25 MHz Analog-to-Digital Converter (ADC) frontend

• Advanced high-performance digital control loop

• Smooth AC zero-crossing control

• Switching frequency extension for improved Electromagnetic Interference (EMI) performance

• Support for multiple operation modes, including Continuous Conduction Mode (CCM), Discontinuous Conduction Mode (DCM), and Burst Mode

• Rapid loop response

• Compatibility with high DC input voltage

• RMS power measurement capability

• Intelligent relay control and surge current control

• Control for X capacitor discharge

• Comprehensive fault protection, encompassing cycle-by-cycle current limiting protection, surge overvoltage protection, input voltage dip and recovery protection, among others

• Low power consumption, with supply current as low as 1mA in Sleep Mode

• Interfaces for I2C and UART, programmable through an easy-to-use Graphical User Interface (GUI)

• Available in QFN-24L packages

HP1011: High-Performance Digital Dual-Phase Interleaved PFC Controller

HP1011 is Hynetek's first digital controller for dual-phase interleaved CCM PFC, featuring average current control. Its digital architecture is based on a high-speed digital state machine structure, integrating a high-performance analog front-end and high-speed comparators, ensuring real-time high-performance control of the PFC. The HP1011 can intelligently switch between Continuous Conduction Mode (CCM), Discontinuous Conduction Mode (DCM), and Burst Mode, offering excellent light-load efficiency. The chip itself has a low power consumption of just 30 mW, with a sleep mode where the supply current drops to 1 mA. HP1011 supports automatic channel management, smoothing load transitions at lower power conditions, improving the PFC converter's load transient response, and boosting efficiency under mid-to-low loads. It also ensures that the effective value deviation of inductor current between phases is less than 5%.HP1011 integrates comprehensive programmable protection functions, including cycle-by-cycle current limit protection, surge overvoltage protection, input voltage overvoltage/undervoltage protection, output voltage overvoltage/undervoltage protection, and output feedback voltage open-circuit protection, with all protection parameters and enable/disable settings configurable independently. HP1011 allows for easy configuration of chip functionalities through a Graphical User Interface (GUI) software, greatly facilitating end-product design and shortening customers' time-to-market.

As China's first digital CCM dual-phase interleaved PFC chip solution, its flexible design features make it suitable for a wide range of systems, including air conditioners and white goods, high-performance computers, 5G/telecommunications power supplies, industrial power supplies, Ultra-High Density (UHD) power supplies, and PFC power supplies with IGBTs.


(1000 W evaluation board utilizing the HP1011 controller)

Chip Features:

• High-flexibility digital PWM, supporting operating frequencies from 20 kHz to 200 kHz

• High-performance analog front-end

• High-performance digital control loop

• Enhanced dynamic loop response

• Multi-mode operation in CCM (Continuous Conduction Mode), DCM (Discontinuous Conduction Mode), and Burst modes

• Dynamic current balancing between phases for inductor currents

• Cycle-by-cycle (CBC) peak current limiting

• Programmable single-phase shedding (Phase Shedding)

• Support for high-voltage DC input

• RMS power metering

• Intelligent relay control and surge current control

• X-capacitor discharge control

• A comprehensive set of programmable protection features

• Low power consumption, with a supply current as low as 1mA in Sleep Mode

• I2C and UART interfaces for programming via an easy-to-use graphical user interface (GUI)

HP1012: Digital Totem Pole PFC Controller with 650 V Half-Bridge Gate Driver

The HP1012 is a totem pole bridgeless PFC digital controller that integrates a 650 V line frequency synchronous rectifier half-bridge driver, packaged in a 7.8 mm x 8.2 mm SSOP-24L package. It builds upon the efficient, flexible, and compact characteristics of the HP1010 chip by incorporating a half-bridge driver, thereby offering higher integration and cost-performance ratio.

(Evaluation Board with HP1012)

Chip Features

• High-Flexibility Digital PWM Control

• PWM frequency range from 20 kHz to 200 kHz

• Soft start during AC line zero crossing

• Frequency spread-spectrum to enhance EMI performance

• Integrated 650V half-bridge driver for slow switch with 2.5A driving current

• High-Performance Control Loop

• 25 MHz ADC for line voltage, output voltage, and current detection; 12.5 MHz ADC for output voltage

• Enhanced dynamic loop response

• Input voltage feedforward to prevent reverse currents during AC voltage dips

• Supports high-voltage DC input • RMS-based power metering

• Surge current control with programmable relay delay

• Discharge of X capacitors in both channels during shutdown

• Multi-Mode Operation • Continuous Conduction Mode (CCM) under heavy loads

• Discontinuous Conduction Mode (DCM) under light loads

• Bypass or hiccup mode under no load

• Comprehensive Protection Features

• Fast overvoltage, undervoltage, and overvoltage protection

• Cycle-by-cycle current limit, average current overcurrent protection

• NTC thermal protection

• Built-in MTP for storing custom configurations

• I2C interface for programming via an easy-to-use GUI

• Packaged in SSOP-24L
