Hynetek-PDSource

The most popular PD source controller products

The USB PD Source controller series products launched by Hynetek have all passed the PD3.0 and PPS certifications of USB-IF. They have many advantages such as high reliability, high compatibility, low power consumption, simple application way, and compatibility with multiple protocols, wildly accepted by customers.

Products List

Part No.	PD3.0	PDO Range	PPS	Apple 5V2.4A	QC2.0/3.0	AFC & FCP	SCP	Rsense	Multi-output Support	VCONN & eMarker Detect	Program Memory	VBUS Switch	Cable IR Compensation	Package	Power Range
HUSB382A	√	5 V, 9 V, 12 V, 15V, 20V FPDOs, 2 APDOs	Two APDOs	√	√（QC3+ Class A or class B ）	√	√	10mΩ	USB Type-C and USB Type-A Dual-Port	-	Two-time	Internal two N-MOS	0, 60mΩ, 120mΩ, 180mΩ	QFN-32L (4 mm x 4 mm)	18 W~65 W
HUSB381	√（PD3.1）	5 V、9 V、12 V、15 V、20 V	Two APDOs	-	-	-	-	10mΩ	-	-	Two-time	internal N-MOS	0, 60mΩ, 120mΩ, 180mΩ	ESSOP-10L	18W~65W
HUSB391	√（PD3.1）	5 V、9 V、12 V、15 V、20 V	Two APDOs	√	√（QC3.0+ Class A or Class B）	√	√	10mΩ	1C2A	-	Two-time	External N-MOS	0, 60mΩ, 120mΩ, 180mΩ	QFN-40L (5 mm x 5 mm)	18W~65W
HUSB382	√（PD3.1）	FPDO 5 V-12 V	Two APDOs	√	√（QC3+ Class A ）	√	√	10mΩ	USB Type-C and USB Type-A Dual-Port	-	Two-time	Internal two N-MOS	0, 60mΩ, 120mΩ, 180mΩ	QFN-32L (4 mm x 4 mm)	20 W
HUSB801【Integrated Buck Controller】	√（PD3.1）	FPDO 5 V-20 V APDO 3.3 V-21 V	Two APDOs	√	√（QC3+ Class A or Class B）	√	√	10mΩ	USB Type-C and USB Type-A Dual-Port	-	Two-time	External N-MOS	0, 60mΩ, 120mΩ, 180mΩ	QFN5×5-40L	18W~65W
HUSB390	√（PD3.1）	FPDO 5 V-20 V APDO 3.3 V-21 V	Two APDOs	√	√（QC3+ Class A or Class B）	√	√	10mΩ	2C/2C1A	-	Two-time	External N-MOS	0, 60mΩ, 120mΩ, 180mΩ	QFN5×5-40L	18W~65W
HUSB352	√（PD3.1）	PDO 5 V-12 V; 5 V Prog and 9 V Prog APDOs	Two APDOs	√	√	√	√	5 mΩ	-	-	One-time	Internal N-MOS	0, 50 mΩ, 100 mΩ, 150 mΩ	QFN-24L	18W~36W
HUSB338D	√	5 V, 9 V and 12 V FPDOs;5 V Prog and 9 V Prog APDOs	Two APDOs	√	√	√	√	-	-	-	1 time	-	-	SOP-8L	18 W~36 W
HUSB365	√（PD3.1）	FPDO 5V-20V APDO 3.3V-21V	Two APDOs	√	√（QC3+ Class A or Class B）	√	√	10mΩ	USB Type-C and USB Type-A Dual-Port	-	Two-time	External N-MOS	0, 60mΩ, 120mΩ, 180mΩ	QFN4X4-24L、QFN3X3-20L	18 W~65 W
HUSB380	√（PD3.1）	FPDO 5V-23.5V APDO 3V-21V	Two APDOs	√	√	√	√	5mΩ	-	-	One-time	Internal N-MOS	0, 50mΩ, 100mΩ, 150mΩ	QFN4x4-32L	15W~65W
HUSB361	√	FPDO 5V-23.5V APDO 3V-21V	Two APDOs	√	√	√	√	5mΩ	-	-	One-time	External N-MOS	0, 50mΩ, 100mΩ, 150mΩ	SSOP-10L、QFN3X3-16L、QFN4X4-16L	15W~65W
HUSB362	√	FPDO 5V-28V APDO 3.3V-21V	5VProg 9VProg 15VProg 20VProg	√	√	√	√	5mΩ	Y	Y	Multi-time	External N-MOS	0, 50mΩ, 100mΩ, 200mΩ	SOP-14L、QFN16L、QFN24L	18~140W
HUSB360	√	FPDO 5V-23.5V APDO 3V-21V	Three APDOs	-	-	-	-	5mΩ	Y	Y	Multi-time	External N-MOS	0, 50mΩ, 100mΩ, 150mΩ	SSOP-10L	18~100W
HUSB338C	√	FPDO 5V-12V APDO 3V-11V	5V Prog & 9V Prog	√	√	√	√	5mΩ	-	-	One-time	External N-MOS	100mΩ	QFN3x3-16L	18~30W
HUSB338A	√	FPDO 5V-12V	-	-	√	-	-	5mΩ	-	-	One-time	External P-MOS	100mΩ	QFN4x4-16L	18W
HUSB338L	√	FPDO 5V-15V APDO 3V-16V	One APDO	-	√	-	-	5mΩ	-	-	One-time	External P-MOS	0 and 100mΩ	SOP-14L QFN4x4-16L	18~45W
HUSB339A	√	FPDO 5V-12V	-	√	√	-	-	5mΩ	-	-	One-time	External P-MOS	100mΩ	QFN4x4-16L	18W
HUSB339B	√	FPDO 5V-12V	-	√	√	√	-	5mΩ	-	-	One-time	External P-MOS	50mΩ	QFN4x4-16L	20W
HUSB339【Not Recommended For New Designs 】	√	FPDO 5V-23.5V APDO 3V-21V	Two APDOs	√	√	-	-	5mΩ	Y	Y	Multi-time	External P-MOS	0, 50mΩ, 100mΩ, 150mΩ	SOP-14L QFN4x4-16L	18~100W
HUSB350	√	PDO 5V-23.5V APDO 3V-21V	Three APDOs	√	√	√	-	5mΩ	Y	Y	Multi-time	External P-MOS	0, 50mΩ, 100mΩ, 200mΩ	SOP-14L QFN4x4-16L	18~100W

Hot Products

HUSB350

High-performance and highly integrated PD Source controller

Check the details

HUSB351

Chips specially designed for low-power Type-C applications

Check the details

HUSB339B

High-performance and highly integrated PD Source controller

Check the details
